HXGN17-12 box type fixed AC metal enclosed ring network switchgear is an indoor high-voltage complete set of equipment widely used in power distribution systems, mainly used to receive and distribute 6-12kV three-phase AC 50Hz electrical energy.
Power distribution function
Suitable for urban ring network power supply, terminal distribution networks, and industrial power plants, undertaking the tasks of receiving, distributing, and protecting electrical energy, especially suitable for the distribution needs of factories, mines, residential areas, high-rise buildings, and box type substations.
Safety standards
Compliant with the national standard GB3906 "3-35kV AC Metal Enclosed Switchgear" and the international standard IEC298, it has a complete "five prevention" mechanical interlocking function to ensure operational safety.
Operation mode: Supports manual/electric operation and can achieve remote control.
Safety process: The grounding switch can only be closed after the load switch is opened, and the cabinet door can only be opened after the grounding switch is closed. Reverse operation is prohibited by the interlocking mechanism.
Maintenance requirements: Regularly check the status of fasteners, busbar contact points, and the effectiveness of mechanical interlocking, and confirm the status of components through observation windows after power failure.
Urban distribution network: Implementing energy distribution and fault isolation in the ring network power supply system of residential communities.
Industrial electricity: As the core equipment for in plant substations or workshop power distribution, it ensures continuous production.
This device, through modular design and multiple security mechanisms, balances efficient power distribution and operational reliability in a compact space, making it a key infrastructure for modern power distribution networks
